Cornel
Curved
-
Italian design & manufacture, certified to EN442
-
Made to order curved radiator
-
2, 3 and 4 column options
-
2 heights in up to 40 sections
-
Wall Brackets as standard
-
Optional Welded Feet
-
RAL 9016 White as standard
-
23 RAL colours & 10 special finishes
-
Delivery in 6 weeks from written sign off of technical drawings
Our CORNEL Curved radiators are made to order and can be curved to fit bay windows. Wall brackets are supplied as standard, optional welded feet are available, please specify at time of order.
Radiators can be curved using up to 40 sections, minimum 10 sections (450mm). It is essential to always know how much heat you need to keep your room comfortable. Use our online Heat Output Calculator to work out how much heat you will need for your room before you size your straight radiator. Curving is a precise process and as such, accurate measurements and calculations must be made and checked before production can begin. Since our CORNEL Curved is made on a bespoke basis to your exact requirements, we have created a specification form to make the process as easy as possible;
To order your curved radiator follow these simple steps;
-
Download the specification form which explains how to measure for your curved radiator, we can also email the specification form to you direct by calling 01342 306880.
-
When you have reviewed the specification form, double-check your measurements are correct to see how your radiator will fit in your space.
-
Complete the specification form with the dimensions of your bay and return it to your chosen merchant/installer to place an initial order.
-
You will receive a technical drawing of your bay and requested measurements from your merchant and if you are happy you will need to sign the document.
-
Use the signed specification form to place your order with your merchant/installer to start production.
Please note; once you have signed off your drawings and ordered your curved radiator it cannot be cancelled or returned.
Calculate the number of sections you need by dividing the required BTU (Watt) output with the output per section; e.g 4500 BTUs divided by 225 = 20 sections, based on 4 column, 500mm high sections (always round up to the next whole number of sections). If the use of this section size does not work in the available space, try a different column option or if possible a different height.
Our CORNEL Curved radiators are made to order and can be curved to fit bay windows. Wall brackets are supplied as standard, optional welded feet are available, please specify at time of order.
Radiators can be curved using up to 40 sections, minimum 10 sections (450mm). It is essential to always know how much heat you need to keep your room comfortable. Use our online Heat Output Calculator to work out how much heat you will need for your room before you size your straight radiator. Curving is a precise process and as such, accurate measurements and calculations must be made and checked before production can begin. Since our CORNEL Curved is made on a bespoke basis to your exact requirements, we have created a specification form to make the process as easy as possible;
To order your curved radiator follow these simple steps;
-
Download the specification form which explains how to measure for your curved radiator, we can also email the specification form to you direct by calling 01342 306880.
-
When you have reviewed the specification form, double-check your measurements are correct to see how your radiator will fit in your space.
-
Complete the specification form with the dimensions of your bay and return it to your chosen merchant/installer to place an initial order.
-
You will receive a technical drawing of your bay and requested measurements from your merchant and if you are happy you will need to sign the document.
-
Use the signed specification form to place your order with your merchant/installer to start production.
Please note; once you have signed off your drawings and ordered your curved radiator it cannot be cancelled or returned.
Calculate the number of sections you need by dividing the required BTU (Watt) output with the output per section; e.g 4500 BTUs divided by 225 = 20 sections, based on 4 column, 500mm high sections (always round up to the next whole number of sections). If the use of this section size does not work in the available space, try a different column option or if possible a different height.
